M5StickC DAC HAT MCP4725

DescriptionDAC_HAT is also a type of C-HAT specifically design for M5StickC controller. Same as DAC unit, this is a voltage output DAC converter for stickc. It can generate a voltage of 0～3.3V. Packed with a DAC converter chip MCP4725, which is low-power, high accuracy, single-channel, 12-bit buffered voltage output Digital-to-Analog Converter (DAC) with a non-volatile memory (EEPROM). Its on-board precision output amplifier allows it to achieve rail-to-rail analog output swing. The DAC input and configuration data can be programmed to the non-volatile memory (EEPROM) by the user using the I2C interface command. I2C address: 0x60 Product FeaturesM5StickC CompatibleOutput: 0～3.3VSoftware Development Platform: Arduino, UIFlow(Blockly, Python)MCP472512-BitResolutionExternal A0 Address PinNormalorPower-DownModeFast Settling Time of 6 μs (typical)ExternalVoltageReference(VDD)Rail-to-RailOutputLowPowerConsumptionSingle-SupplyOperation:2.7V to 5.5VI2C Interface: address 0x60ExtendedTemperatureRange:-40°Cto 125°CInclude1x DAC HAT1x 2 Pin 3.96 Pitch TerminalApplicationSetPointorOffsetTrimmingSensorCalibrationClosed-LoopServoControlLowPowerPortableInstrumentation • PCPeripheralsDataAcquisitionSystemsLearnLinks Datasheet –
