12V 2A Power Supply

Support Raspberry Pi Compute Module IO Board and all of EDATEC’s 12V input computers. ED-PSU1202 is a single-phase 24 watts, 12V 2A output power supply, which is designed by Kuantech Cooperate and marketed by EDATEC. ED-PSU1202 offers 4 versions: UK, Europe, Australia & USA by a main body and 4 changeable plugs. Parameters: Rated input voltage: 100-240Vac Operating range: 90-264Vac Rated input frequency: 50/60Hz /- 3Hz Rated input current: 0.6A max. Maximum input power: 29.1W Input current (no-loading): ≤25mA Power consumption (no-loading): 0.075W MAX DC output voltage: 12.0V Minimum load current: 0.0A Rating load current: 2A Rating output power: 24.0W Line regulation: ±5% Ripple and noise: 150 mVp-p Switching efficiency: 86.8% minimum output current from 100%, 75%, 50%, 25%, 76.8% minimum 10% load Protection: Over-voltage, Short-circuit, Over current Reliability level: 50K hours MTBF @ 25° C (rated input voltage, and using the BELLCORE SR-332 method). DC output voltage must be Safe Extra Low Voltage (SELV) & Limited Power as defined by IEC60950-1 Warranty life: All E-Capacitor life must meet 5 years at 25℃ ambient.( 115V/60Hz and 230V/50Hz) The operating temperature: 0~40°C. Output connector: 5.5mm/2.5mm DC plug
