Wilo Booster Pump Controller – HiControl 1

Make: Wilo Phase: 1 Rated voltage U: 220/230/240 V Mains frequency f: 50 Hz Min. rated current I: 2.0 A Max. rated current per pump I: 10.0 A Protection class: IP65 Max. fluid temperature: 50 deg C Max. ambient temperature: 50 deg C Max. volume flow Q: 8 m3/h Connection input: G 1 Connection output: G 1 Material housing: PA6 Net weight approx.: 1.10 kg Electronic control and regulation accessories. The Wilo HiControl 1 series is used for borehole pumps to enable automatic operation. Wilo-HiControl 1 protects the pump against operation with low volume flow. Thanks to a volume flow sensor and pressure sensor, Wilo-HiControl 1 automates the pump between two values, the start-up pressure and the shut-down volume flow. If the pressure in the network is lower than the start-up pressure, Wilo-HiControl 1 starts the pump. The pump continues to operate until the volume flow falls below the value of the shut-off volume flow. The interior small container prevents water hammering and cycling. Wilo-HiControl 1 can be mounted on surface pumps or connected to submersible pumps for domestic water supply. Special features Simple installation Especially compact design makes it suitable for many types of installation locations High operational reliability due to electronic fault signal Protection of the connected pumps due to built-in protection against low water levels Simple operation due to clear operating state display No additional diaphragm pressure vessel required Perfect corrosion protection, due to rust-free materials Inline version with input and output in vertical axis and uniform thread connections, suitable for direct connection to the pump housing or wall surface installation with a wall bracket (accessories).
